Autobacs 4CH Black Box Recorder DV456

The DV456 is a high-quality and durable black box recorder with advanced features. It has a 4-channel high definition DVR and GPS logging capabilities. The unit is designed to withstand rugged conditions with its IP69K waterproof rating. It also supports a 2.5 inch SATA SSD for storage and has features like Wifi connectivity, G-Sensor for detecting sudden movements or impacts, motion detection for capturing footage, and compatibility with reverse cameras for added convenience.

Video Display Mode: Single/Split/Triple/Quad

• Record Type: Quad

• GPS: Yes

• WIFI: Yes

• Vehicle Tracking: Yes – Vehicle Tracking History

• Max Resolution: 1920 x 1080 (100FPS)

• Real Time Recording: Yes – Auto or Scheduled

• G-Sensor: Yes

• Motion Detection: Yes

• AV Output: AHD & CVBS (Selectable)

• Monitor View: Normal/Mirror/Flip Image Selectable

• Video Compression: H.264

• Reverse Camera Compatible: AHD & CVBS

• Camera Connection: 4 x 4-Pin (M)

• Lockable Storage: Yes

• Alarm Input: 6 Channel

• Alarm Output: 2 Channel

• Speed Signal: Yes

• Timer Recording: Yes

• Adjustable Frame Rate & Bit Rate: Yes

• User Password Protection: Yes

• Operating Temperature: -20°C to +70°C (<80% RH)

• Input Voltage: 10 to 32 Volts DC

• Power Consumption: 48W (Max), <5mA (Standby)

• AI Algorithm: DMS/ADAS/BSD/AVM

• Dimensions: 183 x 38 x 148mm

• IP Rating: IP69K

• Anti Vibration Rating: MIL-STD-810g

• Software: Windows client & Web portal

INCLUDES

• 9 PIN power cable

• DVR lock keys

• 10 PIN alarm wire

• Remote control

• 6 PIN to 4 PIN Video output lead

• GPS Antenna

• Wi-Fi Antenna
